GN Solids Control is known as one of the separation solution provider. One of the fields where GN’s solution can be applied is mining sludge separation. In some mining area, the operators use high pressure water to flush the ore to get the small size ore quickly, while the problem is the ore need to be separated out from the water. Dewatering equipment is needed to do this job.GN designed 2-step separation system for the client from Vietnam. It has coarse separation and fine separation.
The shaker unit is always used to be the coarse separation equipment. With high vibration force, the shaker unit could remove out the solids in sludge with size large than the mesh size of the screen. The ore is always rigid and grinding, thus, the screen fixed on the shaker unit could be polyurethane material for longer lifetime. This system adopted GN shaker unit with new designed shaker deck with easy access for sludge feeding.
It was the 6th year for GN to show at the OTC. As leading brand of separation solution brand in China, in the past nearly 10 years since the foundation, GN developed the normal solids control equipment, waste cuttings management system. Till now, GN’s oily sludge treatment and soil remediation solution are also completed and available. Every year at the OTC, GN will brought new releases as keeping improving is one the critical features of GN Solids. It is the clients’ feedback and comments urge GN continuously going forward. And in the mean while, GN is glad to bring the user-friendly equipment and solution to all the clients, not only take convenience buy also make clients’ more profit. By now, more and more professionals in the industry have paid close attention on GN Solids. GN is also looking forward the future cooperation.
1) New released shale shaker
GN new released shale shaker adopts the gear rack technology which makes replacing of the shaker screen much easier than ever before. Operators only need one ratchet wrench to take off the old screens and fix the new ones. More interesting is by using the same ratchet wrench, operators can adjust the shaker deck angle during the shaker running so that to make the discharged cuttings much dryer or wetter. Another one feature of GN shaker is the sealing technology on the screen frame. Hollow seal strips are embedded on the U type stainless steel screen frame. Using the hammer for embedding, taking off the old rubbers could be done even manually. This type seals ensure the sealing performance in the maximum degree.
This week, one set of 500 GPM mud recycling system for an Africa client is ready for delivery. This mud recycling system will be used in a trenchless drilling project for recovery of used drilling fluids, this could greatly save the cost on water and mud material, and in the meanwhile, reusing of the drilling fluids is good for environmental protection.Different from the previous mud recycling system, this time, the mud tank was designed trailer mounted. The advantage of trailer mounted mud system is easy for transportation; a tractive drive can move the mud system from one site to another without involving the crane for lifting the equipment.
This week, GN just finished the fabrication of a batch of solids control equipment for 3 sets oil rig. This order is for a Europe client, and soon later all the equipment would be shipped out. GN Solids Control, as a leading manufacturer especially for solids control equipment and waste management equipment, since the foundation of the company in the year of 2007, has already got the certificates of API, HSE,CE and CR-TU. GN’s products are acceptable in more and more countries and regions. Turn impossible into possible, that is what GN’s ever committed to.
This order includes 3 types main solids control equipment, shale shaker, mud cleaner and decanter centrifuge. GN has upgraded the equipment design few times, below some features on the equipment will make clear why customer choose GN. Shale Shaker – the shale shaker in this order is used to be the primary shaker in the oil rig mud recycling system. It has 4 panels shaker screenwith each size of 585x1165mm, total screen area 2.7 square meters. At both sides of the shaker, bolted type shaker deck fixing design make it easy for avoiding the shaker deck vibration during transportation. The horizontal beams on both sides of the deck walls make the shaker deck much stronger to bear higher G force. Screen support frame is made of stainless steel for anti corrosion purpose. The embedded hollow rubber seals on screen frame perform a good sealing function and easy for replacement.
Drilling cuttings management equipment are used for further treatment of the drilling cutting discharged from the solids control primary shale shaker. By doing this process, more drilling fluids could be recovered. Environmental protection regulations request the driller to take the drilling cuttings management system into the drilling site. One GN’s old client from South America who ever got over ten units decanter centrifuge ordered the 2 sets oil based drilling cuttings management system. “I need to have this type of equipment to help me expend my business. And the GN’s equipment so far works well, that’s why I order them.” Said by GN client.GN’s drilling cuttings management system was firstly released in the year of 2014, in the whole year of 2015, with the petroleum industry going down, GN’s waste cuttings management system on the contrary brought many orders for GN.
The 2 sets cuttings management system already shipped out last week. All 3 main cuttings management equipment are included in the system.
